Power:93 kW/91 kW
Rated Load Capacity:5 Tons
Max Travel Speed:32 km/h /40 km/h
Rated Load Capacity:5 Tons
Max Travel Speed:32 km/h /40 km/h
| Model | HW5010-A |
| Engine | Weichai (Optional: Yuchai or Cummins) |
| Power | 93 kW |
| Emission Standard | China Stage III / Stage IV |
| Operating Weight | 12.05 Tons |
| Rated Load Capacity | 5.0 Tons |
| Max. Lifting Height | 9.45 m |
| Overall Dimensions (LWH)(Including Forks) | 7650 x 2500 x 2700 mm |
| Overall Dimensions (LWH)(To Fork Face) | 6400 x 2500 x 2700 mm |
| Hydraulic Oil Capacity | 135 L |
| Fuel Tank Capacity | 140 L |
| Axles | Wet braking axles |
| Transmission | Static shifting (Optional: Power shift / Shifting while driving) |
| Cabin | Luxury cabin |
| Display Screen | 10-inch (Optional: 360° panoramic camera system) |
| Hydraulic System | Rexroth / Nuoman |
| Telescopic Boom | Hexagonal integrated bending design |
| Boom Material | High-strength structural steel |
| Frame Leveling Function | ±8° |
| Tire Model | 17.5-25 |
| Max. Travel Speed | 32 km/h |
| Quick Hitch | Optional |
| Model | HW5010-B |
| Engine | Yuchai |
| Power | 91 kW |
| Emission Standard | National II (China) |
| Operating Weight | 12500 kg |
| Rated Load Capacity | 5.0 Tons |
| Max. Lifting Height | 10.0 m |
| Dimensions (LWH) | 6400 x 2350 x 2550 mm |
| Hydraulic Oil Capacity | 170 L |
| Fuel Tank Capacity | 195 L |
| Axles | Air brake axles (Dry type) |
| Cabin | Luxury cabin |
| Transmission System | Hydraulic torque converter |
| Drive Mode | Full electronic control |
| Gears | F4 / R4 (4 Forward / 4 Reverse) |
| Telescopic Boom | 2-Section |
| Boom Material | BS1000 High-strength manganese steel |
| Forks | 1220 mm Floating/Sliding pallet forks |
| Frame Leveling Function | None |
| Tire Model | 440/80R24 Tubeless tires (Advance Brand) |
| Max. Travel Speed | 40 km/h |
| Quick Hitch | Hydraulic quick coupler |
| Hydraulic System | Electro-hydraulic load-sensing proportional system |
| Engine Hood | Fully-opening stamped steel hood |
| Remarks | Includes outriggers and cast iron counterweight |
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
