Swing speed: 0-3rap
Engine model: Weichai
Power: 140kw190hp
Engine model: Weichai
Power: 140kw190hp
1. Standard environmental protection national 5 engine, intercooled supercharged, automatically air-cut brake, high and low speed driving.
2. The multi-way valve adopts the Lujiate large-flow double valve, double-in and double-out, double oil circuit, the hoisting system is faster and more powerful.
3. Large-diameter four-way central revolving body, equipped with a revolving brake valve to prevent slippage, with reliable buffer self-locking function.
4. The slewing center is equipped with a touch-type electric disc, which can rotate 360 degrees infinitely.
| Model | HWFT16T |
| Chassis models | FUTON |
| Max. loading capacity | 16000kg |
| Crane jib U type | 8m*5 section |
| Max. lifting height | 33.9m |
| Outrigger span (mm) | 6400*5700 |
| Overall Dimensions | 10800*2370*3300 |
| Motor Power | 15kw (18.5kw) |
| Lifting speed | Three pumps combined |
| Swing speed | 0-3rap |
| Engine model | Weichai |
| Power | 140kw190hp |
Quote now for the best price.
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
