Drilling depth: 1500m
Drilling diameter:105-1000mm
Rotating torque: 31000*15500 Nm
Drilling diameter:105-1000mm
Rotating torque: 31000*15500 Nm
Crazy Sale Day: Submit the form to get order discounts and coupons!
| Model | HW-1500s |
| Maximum drilling depth | 1500 m |
| Drilling diameter | 105-1000 mm |
| Working air pressure | 1.65～8 MPa |
| Total gas consumption | 16-120 m³/minute |
| Drill rod length | 9.6 m |
| Drill rod diameter | 114/127 mm |
| Axial pressure | 16 T |
| Lifting force | 80 T |
| Fast lifting speed | 28 m/min |
| Fast feeding speed | 44 m/min |
| Max rotary torque | 31000*15500 Nm |
| Max rotary speed | 70/140 r/min |
| Big auxiliary winch liftingforce | 5T |
| Small auxiliary winch liftingforce | 2.5 T |
| Jacks stroke | 1.7 m |
| Drilling efficience | 10-35 m/h |
| Moving speed | 3.5 Km/h |
| Uphill angle | 21° |
| Weight of the rig | 28 T |
| Dimension | 11.58*2.6*3.5 m |
| Engine | 康明斯Cummins 264KW |
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
